Vertical Preheater For Lime Production Process
Vertical Preheater For Lime Production Process
Vertical Preheater For Lime Production Process
Vertical Preheater For Lime Production Process
Vertical Preheater For Lime Production Process
  • Vertical Preheater For Lime Production Process
  • Vertical Preheater For Lime Production Process
  • Vertical Preheater For Lime Production Process
  • Vertical Preheater For Lime Production Process
  • Vertical Preheater For Lime Production Process

Vertical Preheater For Lime Production Process

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Incoterm: FOB,CFR,CIF,FCA,CPT

Basic Info

Model No.: 300TPD

Application: Construction, Chemical Industry, Mineral Operation, Other, Quicklime Production Line

Certification: SGS, CE, ISO, Other

Customized: Customized

Automatic Grade: Automatic

Applicable Material: Quicklime

No. Of Push Rod: 8pcs

Hydraulic Device: Optional

Body Height: 4.4m

Feeding Size: 10~50mm

Capacity: 300TPD

Installation: Oversea Engineer Service

Optional Capacity: 200,400,600 TPD

Type: Round Vertical

Additional Info

Packaging: Container Loading

Productivity: 4-19 t/h

Brand: Mingyuan

Transportation: Ocean

Place of Origin: Henan, China

Supply Ability: 20 Sets per month

Certificate: CE, ISO

HS Code: 8474100000

Port: Qingdao Port,Tianjin Port,Shanghai Port

Product Description

Vertical Lime Preheater, or Vertical Preheater, always works with Rotary Kiln and is installed before the rotary kiln, it can make use of heat from the rotary kiln, as we know that the waste gas from the rotary kiln is still quite high, so there will be a lot of heat wasted if discharge the gas into the air directly. and the efficiency of the lime production plant will be lower, for example, if you use a rotary kiln with model 3.2x52m, with viertical lime preheater, the capacity for limestone can reach to 300 t/d, its capacity will be less than 300 t/d if the vertical lime preheater is not presented.


Vertical Preheater

Technical Parameter of vertical preheater /vertical lime preheater

Model

No. of push rod

Body height(m)

Capacity(t/d)

Feeding size(mm)

YRQ-04

4

4

200

10~50

YRQ-06

6

4

300

10~50

YRQ-08

8

4.4

400

10~50

YRQ-12

12

4.4

600

10~50

Features and Advantages of vertical preheater /vertical lime preheater:
1. Push head and main parts of body is made of heat resistance steel, so it can work in 1000~1100high temperature, and have long operation life.

2.Refractory bricks liner with good design and sealing, to insure the material is preheated equally and reach to preheating temperature.

3. Recycle the heat energy in waste air that discharge from kiln tail effective, increase utilization ratio of fuel, at the same time, it's benefit to dedust;

4. The vertical preheater is used in calcination system, the length of rotary kiln will be shorten, to reduce the heat loss on the surface of rotary kiln and floor space;

5.With good combined revenues, the capacity will be increased 30%, thermal efficiency will be increased 40% after use vertical preheater.

Lime Preheater

Looking for ideal Vertical Lime Preheater Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Lime Vertical Preheater are quality guaranteed. We are China Origin Factory of Vertical Preheater For Sale. If you have any question, please feel free to contact us.
